产品展示

GW-CRPS800

组件名称规格尺寸77mm(W) × 84mm(H) × 225mm(L)交流输入100-240V/10-5A/50-60HZ直流输出+3.3V.+5V.+12V.+5Vsb.-12V.25A.25A.65A.3A.0.5A.功率额定功率800W,+5V&+3.3V不超过200W主电源接口20+4Pin12V辅助供电接口方（4+4）Pin*1，方8Pin*1D型4Pin接口6个SATA接口2

详细信息

组件名称	规格
尺寸	77mm(W) × 84mm(H) × 225mm(L)
交流输入	100-240V/10-5A/50-60HZ
直流输出	+3.3V.	+5V.	+12V.	+5Vsb.	-12V.
	25A.	25A.	65A.	3A.	0.5A.
功率	额定功率800W,+5V&+3.3V不超过200W
主电源接口	20+4Pin
12V辅助供电接口	方（4+4）Pin1，方8Pin1
D型4Pin接口	6个
SATA接口	2个
风扇	40MM
认证	3C，ROHS认证
